The NITAI PL Series 5.08mm pitch pluggable PCB terminal block is designed for reliable wire-to-board connections in industrial control equipment, power supplies, and automation systems.
Featuring a push-in spring connection, this terminal block provides convenient wire termination without conventional screw tightening. Its pluggable design allows the connector to be connected to or disconnected from a compatible PCB-mounted header during equipment assembly and maintenance.
With a rated current of 20A and an IEC rated voltage of 320V under overvoltage category III and pollution degree 2 conditions, the connector supports solid and flexible conductors from 0.2 to 2.5mm².
The terminal block features a green PA66 insulating housing, copper contacts, and tin-plated wire termination surfaces. It is available in 2-pole and 3-pole configurations for different PCB layouts and wiring requirements.
Typical Applications
- Industrial control boards
- PLC control equipment
- Power supply systems
- Industrial automation equipment
- Electronic instruments
- Control cabinets and electrical assemblies
- PCB-based power and signal connections
NITAI provides pluggable PCB terminal block solutions for different PCB layouts, wiring requirements, and industrial applications. Contact us for dimensional drawings, technical specifications, samples, and OEM/ODM customization options.
