Product Overview

The M12 Power Type Back Mount Male Socket – PCB M16×1.5 / PG9 is designed for reliable power connections in industrial automation equipment, control systems, and power distribution applications.

Its back mount structure allows the socket to be installed from the rear side of the equipment panel, providing a compact and secure M12 power interface. The PCB termination enables direct soldering to a printed circuit board for stable electrical performance and efficient equipment assembly.

Available with M16×1.5 or PG9 mounting thread options, this male socket supports different panel installation requirements and provides dependable performance in demanding industrial environments.

Technical Specifications

Specifications for M12 Power Type Back Mount Male Socket – PCB M16×1.5 / PG9
Product Name M12 Power Type Back Mount Male Socket – PCB M16×1.5 / PG9
Series M12
Structure Type Back Mount Socket
Gender Male
Number of Pins 2, 3, 4, 5, 6, 8, 12, 17
Coding A-Coded, B-Coded, D-Coded
Wiring Method PCB Solder Type
Cable Material PVC, PUR
Thread Specification Array
PG7/PG9 PG9
Shielded Unshielded
Category M12 Connectors

Electrical & Mechanical Parameters

Shell Material Brass (Nickel-plated) / Zinc Alloy (Nickel-plated) / PA
Insulator Material PA / TPU
Sealing Material Epoxy Resin / Rubber
Contact Material Brass / Phosphor Bronze (Gold-plated)
Degree of Protection IP65 / IP67
Insulation Resistance ≥100 MΩ
Contact Resistance ≤5 mΩ
Insertion/Withdrawal Cycles ≥500 Mating Cycles
Operating Temperature -25°C ~ +80°C

Technical Drawing

M12 Power Type Back Mount Male Socket – PCB M16×1.5 / PG9 Technical Drawing

Click image to zoom · All dimensions in mm
